Máquinas Barrenadoras - Series Manual

AD-20

Manual Series

Manual Drilling EDM, With ZNC Function

  • Precision servo motor control for stable drilling.
  • Designed for drilling hardened tool steel,carbides and other conductive materials.
  • Suitable for larger workpieces and plastic molds.
  • Drilling capacity from 0.2mm to 3.0mm.Brass or copper electrodes available.
  • Automatic pressure release function.
  • Long life work table made of stainless steel.

Más Información

  • Especificaciones

    Work Table Dimensions 460x210 mm
    Max. Workpiece Dimensions 630x420 mm
    Table Travel X, Y 300x200 mm
    Z Axis Travel 350 mm
    Ram Servo Travel 150 mm
    Max. Length of Electrode 400 mm
    Electrode Diameter Ø0.2~Ø3.0 mm
    Max. Workpiece Weight 80 kgs
    Dielectric Water
    Capacity of Dielectric 20 Litres
    Machine Weight (NW / GW) 500 / 600 kg
    Packing Dimensions 1240x1210x2240 mm

* Todas las especificaciones están sujetas a cambio sin previo aviso.
