Máquinas de Alambre - Series Wi

Wi-L500S

Linear Type

User Friendly CNC control system

Useful functions are added to simplify the positioning preparation before machining.
Simple user interface, with an edit hot key zone for easy operation.
Movable 3D animation allows user to inspect the cutting process at different angles.
Various compensation functions have been designed to improve the quality of the product.
Various ways of data transmitting, including using Ethernet, USB port, and RS232.

Más Información

Especificaciones

Maximum Workpiece Size (LxWxH)	700x540x295 mm
Work Table Size	640x500 mm
Max. Working Load	300 kgs
X/Y/Z Axis Travel	400/300/300 mm
U/V Axis Travel	100/100 mm
Wire Diameter Range	Ø 0.1~0.3 mm
Max. Taper Angle (°)Workpiece Thickness	±22.5 (100 mm)
Max. Wire Load	10 kgs
Water Tank Capacity	570 L
Net Weight	2100 kgs
Machine Layout (WxDxH)	2800x2200x2150 mm

* Todas las especificaciones están sujetas a cambio sin previo aviso.
