Máquinas de Alambre - Series Wi

Wi-90E

Flushing Type

User Friendly CNC control system

  • Useful functions are added to simplify the positioning preparation before machining.
  • Simple user interface, with an edit hot key zone for easy operation.
  • Movable 3D animation allows user to inspect the cutting process at different angles.
  • Various compensation functions have been designed to improve the quality of the product.
  • Various ways of data transmitting, including using Ethernet, USB port, and RS232.

Más Información

  • Especificaciones

    Maximum Workpiece Size (LxWxH) 1170x680x295 mm
    Work Table Size 970x730 mm
    Maximum Workpiece Weight 1000 kgs
    Drive & Servo 5 axes AC Servo
    Simulations Axis X / Y / U / V (4 axes)
    X/Y Axis Travel 750 / 500 mm
    Z Axis Travel 300 mm
    U/V Axis Travel 100/100 mm
    Wire Diameter Range Ø 0.15~0.3 mm
    Max. Taper Angle (°)Workpiece Thickness ±22.5 (100 mm)
    Maximum Axes Load 10 kgs
    Conductivity Automatic
    Water Tank Capacity 360 L
    Net Weight 4000 kgs
    Dimension (LxWxH) 3200x2700x2250 mm

* Todas las especificaciones están sujetas a cambio sin previo aviso.
